General data

  • Manufacturer: Vestas (Danemark)
  • Model: V117/3300
  • Rated power: 3,300 kW
  • Rotor diameter: 117 m
  • No more available
  • Wind class: IEC IIA (DIBt III)
  • Offshore model: no
  • Swept area: 10,752 m²
  • Specific area: 3.26 m²/kW
  • Number of blades: 3
  • Power control: Pitch
  • Commissioning: 2013

Rotor

  • Cut-in wind speed: 2,5 m/s
  • Rated wind speed: 13 m/s
  • Cut-off wind speed: 25 m/s

Gear box

  • Gear box: yes
  • Stages: 3

Generator

  • Number: 1

Tower

  • Minimum hub height: 91,5 m
  • Maximum hub height: 141,5 m

V117/3300 - Vestas - 3300 kW
Laurent Jobart - Alpha Wind

Power curve




Wind farms in the database


Full list (76 wind farms)
